The RAM-B-202U consists of a 1" / 25 mm B size rubber ball connected to a 2.5" / 5 cm diameter round plate. This mounting component

Includes:: pre-drilled holes using the universal AMPS hole pattern. Features 2.5" / 5 cm round plate connects to RAM® device holders containing the universal AMPS hole pattern Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Hole pattern 4-hole AMPS: 1.181" x 1.496" / 3.0 x 3.8 cm Hole pattern 3-hole 120-Degree: 1.812" / 4.6 cm diameter B size Ball 1" / 25 mm Base diameter 2" / 5 cm Weight Capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.



...

The RAM-B-347U base consists of a B size 1" / 25 mm diameter rubber ball connected to a 2" x 1.7" square base. The base has four pre-drilled holes at each corner, using the universal AMPS hole pattern. Features 2" x 1.7" / 50 x 43 mm square ball base features industry-standard AMPS hole pattern with four pre-drilled holes at each corner Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Hole pattern 4-hole AMPS: 1.181" x 1.496" / 3.0 x 3.8 cm B size Ball 1" / 25 mm 2" x 1.7" / 50 x 43 mm square ball base Weight Capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAM-B-231-2 consists of a 1" / 25 mm diameter rubber ball connected at right angles to a base that contains a flexible metal strap. The strap base tightening screw is encased in a compact housing for a clean, safe finish. The strap is long enough to wrap around handle bar posts found on most ATV, UTV, Snowmobiles, Motorcycles & any other applications you can think of. Features Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Hardware included 1 strap clamp adapter 2 1/4"-20 x 1" machine screws 2 1/4"-20 Nylock nuts 1 Zinc worm drive strap clamp 1 6" rubber strip 1 1/4"-20 U-bolt for 0.5"
- 1" rails 2 rubber caps 1 U-bolt spacer

Dimensions B size Ball 1" / 25 mm Strap clamp diameter 1.57"
- 3.15" / 40
- 80 mm Weight capacity Standard use: 2 lbs /...




...

The RAM-B-309-2U connects to your handlebar clutch/brake clamp, left or right side, & holds two 1" / 25 mm diameter mounting ball. The ball that is connected between the hole centers is removable. The base fits the control clamps on your motorcycle with 40 mm x 6 mm stainless steel hardware, provided in the kit. To see if the RAM-B-309-2 base will mount to your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94" / 24 mm & a maximum of 1.58" / 40 mm. Features Combination brake/clutch reservoir base for motorcycles with two mounting balls Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Hardware included 2 M6 x 55 mm hex bolts 2 1/4-20 x 2" hex bolts 2 1/4"-20 x 2.5" he... ...

The RAM-B-309-1U attaches to your motorcycle s handlebar clutch/brake clamp & features one B size 1" / 25 mm rubber ball. The base fits the control clamps on your motorcycle with 40 mm x 6 mm stainless steel hardware, provided in the kit. To see if the RAM-B-309-1U base is compatible with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The hole centers have a minimum width of 0.94" / 24 mm & a maximum of 1.58" / 40 mm. Features Connects to your handlebar clutch/brake clamp with provided 40mm x 6mm stainless steel hardware Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Hardware included 2 M6 x 55 mm hex bolts 2 1/4-20 x 2" hex bolts 2 1/4"-20 x 2.5" hex bolts 2 1/2" spacers 2 1/4" split lock washers Dimen... ...

The RAM-B-230 double ball adapter consists of two attached B size 1" / 25 mm rubber balls that allow the connection of two B size double socket arms. When measured from ball center to ball center, the length is 1.75" / 4.5 cm. Features The perfect adapter for connecting two B size RAM® Mounts double socket arms for extra extension or articulation Consists of two B size 1" / 25 mm RAM® rubber balls connected by a. 75" /19 mm length post Post is made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Ball size B 1" / 25 mm Socket distance 1.75" / 45 mm Overall length 2.54" / 65 mm Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAP-B-378U consists of a 2.5" / 5 cm composite B size ball base, double-sided adhesive PSA stick pad, & sealed alcohol prep pad. This base will attach to all RAM® B size double socket arms, allowing you to connect a compatible device holder. Features Flex adhesive ball base provides a strong mounting surface in a wide variety of use cases, such as a vehicle dash Included B size 1" / 25 mm RAM® rubber balls allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from high-strength composites for durability & reliability in the most demanding environments

Dimensions Base diameter 2" / 5 cm B size Ball 1" / 25 mm Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAM® motorcycle fork stem base is one of the cleanest & most popular solutions for mounting your favorite device on the center of your bike. Featuring a B size 1" / 25 mm rubber ball, this part is designed to fit into the cylindrical bore wall of fork stems & will work with stems that measure 12 mm to 38 mm (.5” to 1.49”) in diameter. Hardware included 1 expansion plug for 12 mm
- 38 mm (.5"
- 1.49") fork stem holes 1 M5 x 60 mm machine screw 1 steel washer set 1 nut pocket washer set 1 brass Nylock nut Features Designed to fit into the cylindrical bore wall of fork stems Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Range 12 mm
- 38 mm (.5"
- 1.49") fork stem holes B size Ball 1" / 25 mm Weight capacity Standard use: 2 lbs / 900 gr. He...





...

The RAM-HOL-GA48U consists of a high-strength composite cradle that will allow for the attachment of RAM® components that contain the universal AMPS hole pattern. Compatible & interchangeable with a wide range of popular RAM® Mounts, this cradle is ready to compliment your GPS & become the most useful accessory in your vehicle. Included is a set of two nuts & bolts. Included Hardware 2 8-32 x 1/2" machine screws 2 8-32 x 5/8" machine screws 2 8-32 x 3/4" machine screws 2 8-32 Nylock nuts Hole pattern 2-Hole AMPS: 1.912" / 48.5 mm Note This mount requires the standard belt clip button which is included with the purchase of the GPS unit from Garmin. Suitable for Garmin e Trex 10 Garmin e Trex 20 Garmin e Trex 20x Garmin e Trex 22x Garmin e Trex 30 Garmin e Trex 30x Garmin e Trex 32x ...

The RAM-HOL-GA12U consists of a high strength composite cradle & hole pattern that will allow the attachment to all RAM components or mounts that contain the universal AMPs hole pattern. Compatible & interchangeable with a wide range of popular RAM Mounting products, this cradle is ready to compliment your GPS & become the most useful accessory in your vehicle. Included is a set of two nuts & bolts to connect the cradle to any RAM components or mounts that contain the universal AMPs hole pattern. Included Hardware 2 8-32 x 1/2" machine screws 2 8-32 x 5/8" machine screws 2 8-32 x 3/4" machine screws 2 8-32 Nylock nuts Hole pattern 2-Hole AMPS: 1.912" / 48.5 mm Note This mount requires the standard belt clip button which is included with the purchase of the GPS unit from Garmin. Suitable for Garmin Astro 220 Garmin GPS 60 Garmin GPSMAP 60 Garmin GPSMAP 60C Garmin GPSMAP 60CS Garmin GPSMAP 60 C Sx Garmin GPSMAP 60 Cx ...
