The RAM-B-236U consists of a 1" / 25 mm rubber ball connected to a 3/8"-16 threaded post. Thread length is 0.5" / 12.5 mm. The RAM-B-236U will attach to all 1" / 25 mm diameter ball compatible arms. Features Ball adapter features 3/8"-16 threaded post & stainless steel split lock washer Included B size 1" / 25 mm RAM® rubber balls allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from high-strength composites with stainless steel thread post for durability & reliability in the most demanding environments

Dimensions Thread pitch 3/8"-16 B size Ball 1" / 25 mm Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAP-B-366U universal camera & camcorder base consists of a B size 1" / 25 mm rubber ball, connected to a round plate with a 1/4"-20 camera thread. The round plate provides extra support & stability for the camera it s attached to. The male 1/4"-20 threaded steel stud will connect to any standard female thread found on digital cameras, camcorders, & other devices. Features Universal camera & camcorder base opens your device to the RAM® mounting system Included B size 1" /25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from high-strength composites for durability & reliability in the most demanding environments

Dimensions Thread pitch 1/4"-20 x. 25" B size Ball 1" / 25 mm Base diameter 1.23" / 3.1 cm Weight Capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

For anyone who needs more versatility from their Go Pro® mounting solution, look no further than the RAM® ball adapter for Go Pro® mounting bases. Utilizing the RAM® ball & socket mounting system, simply attach the included B size 1” / 25 mm rubber ball adapter to the Go Pro® base for enhanced adjustability & superior vibration damping – letting you get the most out of your favorite action camera. Features

Includes:: rubber ball connected to a custom action camera adapter compatible with Go Pro® & most other brands Attaches directly to the underside of the action camera to replace the factory mounting bracket Ball base allows for connection to any B size RAM® double socket arm

Dimensions B size Ball 1" / 25 mm Weight Capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.



...

Connect another device to your existing RAM® Mount with the RAM-B-273U Ball Base Adapter. This ball is made up of a 1" / 25 mm ball connecting to a 1/4"-20 threaded stud with a length of 1.6" / 4 cm. The threads on this ball replace the bolt in any B-size socket arm (not included), & the ball connects to the middle of the socket arm on the opposite side of the tightening knob. If you are looking to mount more than one device but cannot locate multiple mounting points on your motorcycle or vehicle, this base is the ideal accessory for connecting both devices off of one mounting base. Features Replace the bolt in any B size double socket arm (not included) to add another 1" / 25 mm B size RAM® rubber ball to your mounting setup Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from powder-coated, marine-grade aluminum for durability & reliability in the most dem... ...

The RAM-B-238U ball base consists of a 1" / 25 mm B size rubber ball connected to a 2.43" x 1.31" / 6.2 x 3.3 cm diamond plate. The diamond plate features two holes that measure 1.912" / 4.85 cm from center to center, matching the industry-standard AMPS hole pattern. This diamond ball base is compatible with a wide variety of RAM® device holders & cradles. Features Diamond plate features industry-standard AMPS hole pattern & measures 2.43" x 1.31" / 6.2 x 3.3 cm Compatible with several RAM® device holders & cradles, ball & socket technology allows for near-infinite adjustability made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Hole pattern 2-hole AMPS: 1.912" / 4.85 cm B size Ball 1" / 25 mm Base size 2.43" x 1.31" / 6.2 x 3.3 cm, diamond shaped Weight Capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAM-B-347U base consists of a B size 1" / 25 mm diameter rubber ball connected to a 2" x 1.7" square base. The base has four pre-drilled holes at each corner, using the universal AMPS hole pattern. Features 2" x 1.7" / 50 x 43 mm square ball base features industry-standard AMPS hole pattern with four pre-drilled holes at each corner Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Hole pattern 4-hole AMPS: 1.181" x 1.496" / 3.0 x 3.8 cm B size Ball 1" / 25 mm 2" x 1.7" / 50 x 43 mm square ball base Weight Capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAM-B-231-2 consists of a 1" / 25 mm diameter rubber ball connected at right angles to a base that contains a flexible metal strap. The strap base tightening screw is encased in a compact housing for a clean, safe finish. The strap is long enough to wrap around handle bar posts found on most ATV, UTV, Snowmobiles, Motorcycles & any other applications you can think of. Features Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Hardware included 1 strap clamp adapter 2 1/4"-20 x 1" machine screws 2 1/4"-20 Nylock nuts 1 Zinc worm drive strap clamp 1 6" rubber strip 1 1/4"-20 U-bolt for 0.5"
- 1" rails 2 rubber caps 1 U-bolt spacer

Dimensions B size Ball 1" / 25 mm Strap clamp diameter 1.57"
- 3.15" / 40
- 80 mm Weight capacity Standard use: 2 lbs /...




...

The RAM-B-309-2U connects to your handlebar clutch/brake clamp, left or right side, & holds two 1" / 25 mm diameter mounting ball. The ball that is connected between the hole centers is removable. The base fits the control clamps on your motorcycle with 40 mm x 6 mm stainless steel hardware, provided in the kit. To see if the RAM-B-309-2 base will mount to your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94" / 24 mm & a maximum of 1.58" / 40 mm. Features Combination brake/clutch reservoir base for motorcycles with two mounting balls Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Hardware included 2 M6 x 55 mm hex bolts 2 1/4-20 x 2" hex bolts 2 1/4"-20 x 2.5" he... ...

The RAM-B-309-1U attaches to your motorcycle s handlebar clutch/brake clamp & features one B size 1" / 25 mm rubber ball. The base fits the control clamps on your motorcycle with 40 mm x 6 mm stainless steel hardware, provided in the kit. To see if the RAM-B-309-1U base is compatible with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The hole centers have a minimum width of 0.94" / 24 mm & a maximum of 1.58" / 40 mm. Features Connects to your handlebar clutch/brake clamp with provided 40mm x 6mm stainless steel hardware Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Hardware included 2 M6 x 55 mm hex bolts 2 1/4-20 x 2" hex bolts 2 1/4"-20 x 2.5" hex bolts 2 1/2" spacers 2 1/4" split lock washers Dimen... ...

The RAP-B-200-2U consists of double 1" / 25 mm B size diameter open sockets with a 360-degree center rotation point & a connecting 180-degree swivel joint. The central pivot point provides unsurpassed adjustability for 1" / 25 mm B size ball bases, device holders, & adapters that are connected via the sockets. Features Double socket swivel & ratchet arm features 360-degree center rotation & 180-degree swivel joint with an overall length of 6.25" / 159 mm & a socket-to-socket length of 5.5" / 140 mm Attaches to any B size RAM® ball component, including mounting bases & device holders Double ball & socket technology allows for near-infinite adjustability of your RAM® mounting system

Dimensions Ball size B 1" / 25 mm Socket distance 5.5" / 140 mm Overall length 6.25" / 159 mm Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...
