The RAM-B-309-1U attaches to your motorcycle s handlebar clutch/brake clamp & features one B size 1" / 25 mm rubber ball. The base fits the control clamps on your motorcycle with 40 mm x 6 mm stainless steel hardware, provided in the kit. To see if the RAM-B-309-1U base is compatible with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The hole centers have a minimum width of 0.94" / 24 mm & a maximum of 1.58" / 40 mm. Features Connects to your handlebar clutch/brake clamp with provided 40mm x 6mm stainless steel hardware Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Hardware included 2 M6 x 55 mm hex bolts 2 1/4-20 x 2" hex bolts 2 1/4"-20 x 2.5" hex bolts 2 1/2" spacers 2 1/4" split lock washers Dimen... ...

The RAP-B-200-2U consists of double 1" / 25 mm B size diameter open sockets with a 360-degree center rotation point & a connecting 180-degree swivel joint. The central pivot point provides unsurpassed adjustability for 1" / 25 mm B size ball bases, device holders, & adapters that are connected via the sockets. Features Double socket swivel & ratchet arm features 360-degree center rotation & 180-degree swivel joint with an overall length of 6.25" / 159 mm & a socket-to-socket length of 5.5" / 140 mm Attaches to any B size RAM® ball component, including mounting bases & device holders Double ball & socket technology allows for near-infinite adjustability of your RAM® mounting system

Dimensions Ball size B 1" / 25 mm Socket distance 5.5" / 140 mm Overall length 6.25" / 159 mm Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAM-B-230 double ball adapter consists of two attached B size 1" / 25 mm rubber balls that allow the connection of two B size double socket arms. When measured from ball center to ball center, the length is 1.75" / 4.5 cm. Features The perfect adapter for connecting two B size RAM® Mounts double socket arms for extra extension or articulation Consists of two B size 1" / 25 mm RAM® rubber balls connected by a. 75" /19 mm length post Post is made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Ball size B 1" / 25 mm Socket distance 1.75" / 45 mm Overall length 2.54" / 65 mm Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAP-B-378U consists of a 2.5" / 5 cm composite B size ball base, double-sided adhesive PSA stick pad, & sealed alcohol prep pad. This base will attach to all RAM® B size double socket arms, allowing you to connect a compatible device holder. Features Flex adhesive ball base provides a strong mounting surface in a wide variety of use cases, such as a vehicle dash Included B size 1" / 25 mm RAM® rubber balls allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from high-strength composites for durability & reliability in the most demanding environments

Dimensions Base diameter 2" / 5 cm B size Ball 1" / 25 mm Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr.

...

The RAM® motorcycle fork stem base is one of the cleanest & most popular solutions for mounting your favorite device on the center of your bike. Featuring a B size 1" / 25 mm rubber ball, this part is designed to fit into the cylindrical bore wall of fork stems & will work with stems that measure 12 mm to 38 mm (.5” to 1.49”) in diameter. Hardware included 1 expansion plug for 12 mm
- 38 mm (.5"
- 1.49") fork stem holes 1 M5 x 60 mm machine screw 1 steel washer set 1 nut pocket washer set 1 brass Nylock nut Features Designed to fit into the cylindrical bore wall of fork stems Included B size 1" / 25 mm RAM® rubber ball allows for connection to any B size RAM® double socket arm, ball & socket technology allows for near-infinite adjustability made from powder-coated, marine-grade aluminum for durability & reliability in the most demanding environments

Dimensions Range 12 mm
- 38 mm (.5"
- 1.49") fork stem holes B size Ball 1" / 25 mm Weight capacity Standard use: 2 lbs / 900 gr. He...





...

The RAM-HOL-GA12U consists of a high strength composite cradle & hole pattern that will allow the attachment to all RAM components or mounts that contain the universal AMPs hole pattern. Compatible & interchangeable with a wide range of popular RAM Mounting products, this cradle is ready to compliment your GPS & become the most useful accessory in your vehicle. Included is a set of two nuts & bolts to connect the cradle to any RAM components or mounts that contain the universal AMPs hole pattern. Included Hardware 2 8-32 x 1/2" machine screws 2 8-32 x 5/8" machine screws 2 8-32 x 3/4" machine screws 2 8-32 Nylock nuts Hole pattern 2-Hole AMPS: 1.912" / 48.5 mm Note This mount requires the standard belt clip button which is included with the purchase of the GPS unit from Garmin. Suitable for Garmin Astro 220 Garmin GPS 60 Garmin GPSMAP 60 Garmin GPSMAP 60C Garmin GPSMAP 60CS Garmin GPSMAP 60 C Sx Garmin GPSMAP 60 Cx ...

The RAM-HOL-GA41U consists of a high strength composite cradle & hole pattern that will allow the attachment to all RAM components or mounts that contain the universal AMPs hole pattern. Compatible & interchangeable with a wide range of popular RAM Mounting products, this cradle is ready to compliment your GPS & become the most useful accessory in your vehicle. Included is a set of two nuts & bolts to connect the cradle to any RAM components or mounts that contain the universal AMPs hole pattern. Included Hardware 2 8-32 x 1/2" machine screws 2 8-32 x 5/8" machine screws 2 8-32 x 3/4" machine screws 2 8-32 Nylock nuts Hole pattern 2-Hole AMPS: 1.912" / 48.5 mm Note This mount requires the standard belt clip button which is included with the purchase of the GPS unit from Garmin. Suitable for Garmin Astro 320 Garmin Astro 430 Garmin GPSMAP 62 Garmin GPSMAP 62s Garmin GPSMAP 62sc Garmin GPSMAP 62st Garmin GPSMAP 62stc Garmin GPSMAP 64 Garmin GPSMAP 64s Garmin GPSMAP 64sc Garmin GPSMAP 64st ...

The RAM-HOL-GA46U consists of a high strength composite cradle for Garmin Montana devices. Included is a set of two nuts & bolts to connect the cradle to any RAM components or mounts that contain the universal AMPs hole pattern. Compatible & interchangeable with a wide range of popular RAM Mounting products, this cradle is ready to compliment your GPS & become the most useful accessory in your vehicle. Included is a set of two nuts & bolts to connect the cradle to any RAM components or mounts that contain the universal AMPs hole pattern. Included Hardware 2 8-32 x 1/2" machine screws 2 8-32 x 5/8" machine screws 2 8-32 x 3/4" machine screws 2 8-32 Nylock nuts Hole pattern 2-Hole AMPS: 1.912" / 48.5 mm Note This mount requires the standard belt clip button which is included with the purchase of the GPS unit from Garmin. Suitable for Garmin Montana 600 Garmin Montana 610 Garmin Montana 610t Garmin Montana 650 Garmin Montana 650t Garmin Montana 680 Garmin Montana 680t ...

The RAM-HOL-GA31U consists of a high strength composite cradle & hole pattern that will allow the attachment to all RAM components or mounts that contain the universal AMPs hole pattern. Compatible & interchangeable with a wide range of popular RAM Mounting products, this cradle is ready to compliment your GPS & become the most useful accessory in your vehicle. Included is a set of two nuts & bolts to connect the cradle to any RAM components or mounts that contain the universal AMPs hole pattern. Included Hardware 2 8-32 x 1/2" machine screws 2 8-32 x 5/8" machine screws 2 8-32 x 3/4" machine screws 2 8-32 Nylock nuts Hole pattern 2-Hole AMPS: 1.912" / 48.5 mm Note This mount requires the standard belt clip button which is included with the purchase of the GPS unit from Garmin. Suitable for Garmin Approach G5 Garmin Oregon 200 Garmin Oregon 300 Garmin Oregon 400c, 400i, 400t Garmin Oregon 450, 450t Garmin Oregon 550, 550t Garmin Oregon 600, 600t Garmin Oregon 650, 650t Garmin Oregon 700 Garmin Oregon 750, 750t ...

With the Garmin spine mount adapter, make any Garmin handheld device featuring an integrated spine connection RAM® Compatible™. This spine mount adapter easily clips into the integrated spine connection on a wide variety of Garmin devices. For use in nearly any application, the included B size diamond base adapter & hardware means that you can connect your Garmin handheld to any RAM® B size mounting base. Features Holder secures any Garmin handheld device with an integrated spine connection RAM® Mounts ball & socket technology allows for near-infinite adjustability made from Powder-coated, marine-grade aluminum for durability & reliability in the most demanding marine environments Weight capacity Standard use: 2 lbs / 900 gr. Heavy-duty use: 1 lb / 450 gr. Compatible Garmin devices Alpha® 100 Approach® G3 Approach® G5 Astro® 320 Astro® 430 Astro® 900 Dakota® 10 Dakota® 20 e Trex® 10 e Trex® 20 e Trex® 20x e Trex® 22x e Trex® 30 e Trex® 30x e Trex® 32x e Trex® Touch 25 e Trex® Touch 35 e Trex® Tou... ...
