HIGHSIDER CNC FRAME CAP Set, 2-piece (160-326) or 7-piece (160-325), suitable for BMW Rnine T from 2014-2016 (complete set). ATTENTION From model year 2016, the frame has been changed on some models. Thus, the cover cap (vehicle side bestrachtet from the left) top right (above the cylinder head- injector) does not fit! SEE PHOTO The black anodized aluminum caps cover the frame holes of the BMW Rnine T. Combined with polished bevels, these caps stand for a noble, stylish design & fit perfectly to our HIGHSIDER CONERO series. Tailor-made for your bike
- the extensive range of accessories from HIGHSIDER is perfectly tailored to your motorcycle. With the highest level of quality & functionality, you can easily customize your bike to your liking.

Dimensions 2-piece set Cap, left = A: 49 mm, B: 42 mm, C: 13 mm Locking cap, right = A: 58 mm, B: 48 mm, C: 10 mm

Dimensions 7-piece set Swingarm cover = A: 49 mm, B: 42 mm, C: 13 mm Swingarm closing lid = A: 58 mm, B: 48 mm, C: 10 mm Upper swing...




...

This special handlebar adapter is suitable for mounting various HIGHSIDER handlebar end weights & handlebar end mirrors directly on the original handlebar of the BMW R nine T. Tailor-made for your bike
- the extensive range of accessories from HIGHSIDER is perfectly tailored to your motorcycle. With the highest level of quality & functionality, you can easily customize your bike according to your wishes.

Dimensions Bolt: M12 Internal thread: M6 Scope of delivery 1 pair of handlebar adapters 161-037 2 x threaded sleeves 2 x washers Suitable for BMW R 1200 Nine T ABS, 2014- BMW S 1000R ABS, 2014-2016


...

This load-independent digital flasher unit is ideal for LED conversions. Equipped with under- & overvoltage protection, the relay provides an absolutely constant flashing frequency & can be used for all turn signals from 1 watt to 21 watts. Other

Features: waterproof, vibration-proof, wear-free & overload-proof. Made in Germany. Tailor-made for your bike
- the extensive range of accessories from HIGHSIDER is perfectly tailored to your motorcycle. With the highest level of quality & functionality, you can easily customize your bike according to your wishes.

Dimensions Length: 20 mm

Width: 20 mm

Height: 13 mm Technical specifications Supply voltage: 5 V
- 16 V Load range: 1 W
- 90 W No quiescent current consumption Simple connections via 2 wires Connect red cable = 12 V (+) with terminal 49, it is recommended to connect a 10 A fuse in front. Black cable = connect ground (-) in series to turn signal switch with terminal 49a Scope of delivery 1 piece flasher unit 208-011 Bracket fo...










...

HIGHSIDER 7 inch LED headlight BRITISH-STYLE TYPE 8
- See & be seen!
- For motorcyclists of utmost importance. The installed

...

HIGHSIDER 7 inch LED headlight BRITISH-STYLE TYPE 8
- See & be seen!
- For motorcyclists of utmost importance. The installed

...

HIGHSIDER CAN-BUS resistor CBW1 with DIP switch. The newly developed HIGHSIDER CAN-BUS resistor CBW1 fits most vehicles that have a CAN-BUS system. The resistor CBW1 provides a required electrical load for their vehicle, which leads to no error message in the cockpit with accessory turn signals when the dip switches are set correctly. In addition, there is a fail-safe feature. That is: In the event of failure of the accessory turn signals due to an electronic defect, an error message is immediately displayed in the cockpit. Features The following resistance values can be set: 150 Ohm 170 Ohm 200 Ohm 240 Ohm 300 Ohm 400 Ohm 600 Ohm 1200 Ohm

Dimensions Height = 11 mm Width = 31 mm (without lugs) Width = 46 mm (with lugs) length = 40 mm Cable length = 200 mm with pins Connections Yellow = Input channel 1 (+) Orange = Output channel 1 (+) Blue = input channel 2 (+) Red = Output channel 2 (+) Gray = Input ground (-) Black = Output ground (-) Scope of delivery 1 piece CAN-BUS resistor CBW1 2...

...

HIGHSIDER 5 3/4 inch LED main headlight CIRCLE, E-approved. The Light Guide technology creates a very homogeneous light ring with daytime running & parking light function. The CIRCLE headlight is available in a high quality metal housing, either for lower or side mounting. The bright joy
- give your bike a distinctive style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case!

Dimensions Diameter headlight insert: 146.5 mm

Depth: 167 mm with glass Mounting side 223-046: with mounting screws M6 Bottom mounting 223-048: with M6 mounting screws Connections 12, 5 Volt DC Green cable = ground White cable = low beam Blue cable = high beam Brown cable = parking light Red cable = daytime running light Variants 223-046
- Black, side mount 223-048
- Black, bottom mount Scope of delivery 1 x main headlight, E-approved Mounting hardware






...

HIGHSIDER 5 3/4 inch LED main headlight CIRCLE, E-approved. The Light Guide technology creates a very homogeneous light ring with daytime running & parking light function. The CIRCLE headlight is available in a high quality metal housing, either for lower or side mounting. The bright joy
- give your bike a distinctive style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case!

Dimensions Diameter headlight insert: 146.5 mm

Depth: 167 mm with glass Mounting side 223-046: with mounting screws M6 Bottom mounting 223-048: with M6 mounting screws Connections 12, 5 Volt DC Green cable = ground White cable = low beam Blue cable = high beam Brown cable = parking light Red cable = daytime running light Variants 223-046
- Black, side mount 223-048
- Black, bottom mount Scope of delivery 1 x main headlight, E-approved Mounting hardware






...

HIGHSIDER 5 3/4 inch main headlight CLASSIC 1 EXTREME for bottom mount. H4 halogen main headlight with a high-quality processed, black aluminum housing with 3 distinctive CNC-milled grooves & a nostalgic shade (length: approx. 25 mm) in retro look. The headlight has an asymmetrical
- only approved for right-hand traffic
- prism reflector & parking light, E-approved. Sensational
- give your bike an unmistakable style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case! Technical specifications Bulb: H4, 12 V 60/55 W Mounting: bottom mount Diameter: 157 mm

Depth: 220 mm Holder center mounting screw to front: 127 mm Holder gap: 18 mm Bottom mount Connections White cable = low beam (+) Green cable = ground of H4 bulb Blue cable = high beam (+) Brown cable = parking light (+) Black cable = ground of parking light (-) Scope of delivery 1 piece, consisting of headlight 223-034 incl. bulb Notes Asymmetrical reflector
- only approved...





...

HIGHSIDER 5 3/4 inch main headlight CLASSIC 1, bottom mount. H4 halogen main headlight in a high quality processed, black or chromed aluminum housing in retro look. The headlight has an asymmetrical
- only approved for right-hand traffic
- prism reflector & parking light, E-approved. Sensational
- give your bike an unmistakable style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case! Technical specifications Bulb: H4, 12 V 60/55 W Mounting: bottom mount Diameter: 157 mm

Depth: 220 mm Holder center mounting screw to front: 127 mm Holder gap: 18 mm Connections White cable = low beam (+) Green cable = ground of H4 bulb Blue cable = high beam (+) Brown cable = parking light (+) Black cable = ground of parking light (-) Variants 223-030
- Chrome plated 223-032
- Black Scope of delivery 1 piece main headlight with bulb Notes Asymmetrical reflector
- only approved for right-hand traffic







...
