HIGHSIDER LED taillight, brake light, turn signal BLAZE. LED tail light, brake light, turn signal in a metal housing with black rubber stem & a compact rectangular shape. The high quality BLAZE has waterproof mini-plugs & is E-approved for rear installation. Not to be overlooked -HIGHSIDER s taillight & taillight/turn signal series give you the safety you need & the look you want
- whether cruiser, sport bike or scooter.

Dimensions A: 39.5 mm B: 55 mm C: 19.5 mm D: 19 mm Threaded bolt: M8 x 1.25 mm Connections Black cable = ground (-) Yellow cable= turn signal (+) Orange cable = tail light (+) Red cable = brake light (+) Variant 254-300
- Black / tinted glass 254-301
- Chrome / clear glass 254-302
- Black / clear glass Scope of delivery 1 pair rear, brake light, turn signal for rear





...

HIGHSIDER LED turn signal BLAZE. The BLAZE model combines powerful LED technology with a modern design. The tinted glass blends harmoniously with the high-quality processed, black metal housing. The turn signals include small, waterproof plugs & a rubber stem, E-approved. Head in the right direction
- with the innovative turn signal series from HIGHSIDER. Show not only where you want to go, but also who you are. This is directional design at its finest.

Dimensions A: approx. 40 mm B: approx. 55 mm C: approx. 20 mm D: 19 mm Threaded bolt M8 x 1.25 mm, length: approx. 20 mm Connections Black cable = ground (-) Red cable = turn signal (+) Variant 204-300
- Black / tinted glass 204-301
- Chrome / clear glass 204-302
- Black / clear glass Scope of delivery 1 pair of turn signals





...

HIGHSIDER LED turn signal BLAZE. The BLAZE model combines powerful LED technology with a modern design. The tinted glass blends harmoniously with the high-quality processed, black metal housing. The turn signals include small, waterproof plugs & a rubber stem, E-approved. Head in the right direction
- with the innovative turn signal series from HIGHSIDER. Show not only where you want to go, but also who you are. This is directional design at its finest.

Dimensions A: approx. 40 mm B: approx. 55 mm C: approx. 20 mm D: 19 mm Threaded bolt M8 x 1.25 mm, length: approx. 20 mm Connections Black cable = ground (-) Red cable = turn signal (+) Variant 204-300
- Black / tinted glass 204-301
- Chrome / clear glass 204-302
- Black / clear glass Scope of delivery 1 pair of turn signals





...

HIGHSIDER LED turn signal / position light unit BLAZE. This unit combines powerful LED technology with a modern design. The tinted glass blends harmoniously with the high-quality processed, black metal housing. The turn signals include small, waterproof plugs & a rubber stem, E-approved. Head in the right direction
- with the innovative turn signal series from HIGHSIDER. Show not only where you want to go, but also who you are. This is directional design at its finest.

Dimensions A: approx. 40 mm B: approx. 55 mm C: approx. 20 mm D: 19 mm Threaded bolt M8 x 1.25 mm, length: approx. 20 mm Connections Black cable = ground (-) for both functions Yellow cable = turn signal (+) White cable = parking light (+) Scope of delivery 1 pair of turn signal/position light 204-304


...

HIGHSIDER CNC FRAME CAP Set, 2-piece (160-326) or 7-piece (160-325), suitable for BMW Rnine T from 2014-2016 (complete set). ATTENTION From model year 2016, the frame has been changed on some models. Thus, the cover cap (vehicle side bestrachtet from the left) top right (above the cylinder head- injector) does not fit! SEE PHOTO The black anodized aluminum caps cover the frame holes of the BMW Rnine T. Combined with polished bevels, these caps stand for a noble, stylish design & fit perfectly to our HIGHSIDER CONERO series. Tailor-made for your bike
- the extensive range of accessories from HIGHSIDER is perfectly tailored to your motorcycle. With the highest level of quality & functionality, you can easily customize your bike to your liking.

Dimensions 2-piece set Cap, left = A: 49 mm, B: 42 mm, C: 13 mm Locking cap, right = A: 58 mm, B: 48 mm, C: 10 mm

Dimensions 7-piece set Swingarm cover = A: 49 mm, B: 42 mm, C: 13 mm Swingarm closing lid = A: 58 mm, B: 48 mm, C: 10 mm Upper swing...




...

This load-independent digital flasher unit is ideal for LED conversions. Equipped with under- & overvoltage protection, the relay provides an absolutely constant flashing frequency & can be used for all turn signals from 1 watt to 21 watts. Other

Features: waterproof, vibration-proof, wear-free & overload-proof. Made in Germany. Tailor-made for your bike
- the extensive range of accessories from HIGHSIDER is perfectly tailored to your motorcycle. With the highest level of quality & functionality, you can easily customize your bike according to your wishes.

Dimensions Length: 20 mm

Width: 20 mm

Height: 13 mm Technical specifications Supply voltage: 5 V
- 16 V Load range: 1 W
- 90 W No quiescent current consumption Simple connections via 2 wires Connect red cable = 12 V (+) with terminal 49, it is recommended to connect a 10 A fuse in front. Black cable = connect ground (-) in series to turn signal switch with terminal 49a Scope of delivery 1 piece flasher unit 208-011 Bracket fo...










...

HIGHSIDER 7 inch LED headlight BRITISH-STYLE TYPE 8
- See & be seen!
- For motorcyclists of utmost importance. The installed

...

HIGHSIDER 7 inch LED headlight BRITISH-STYLE TYPE 8
- See & be seen!
- For motorcyclists of utmost importance. The installed

...

HIGHSIDER cable fixation for mounting on the HIGHSIDER CNC aluminum standpipe clamps, No. 207-402 to 207-419. Can also be used universally. Tailor-made for your bike
- the extensive range of accessories from HIGHSIDER is perfectly tailored to your bike. With the highest level of quality & functionality, you can easily customize your bike according to your wishes.

Dimensions Unbent: L- shape

Width: 20.5 mm

Height: 25, 5 mm Thickness: 0, 5 mm Hole diameter: M5 Scope of delivery Set of 10 cable fixation 207-124






...

HIGHSIDER CAN-BUS resistor CBW1 with DIP switch. The newly developed HIGHSIDER CAN-BUS resistor CBW1 fits most vehicles that have a CAN-BUS system. The resistor CBW1 provides a required electrical load for their vehicle, which leads to no error message in the cockpit with accessory turn signals when the dip switches are set correctly. In addition, there is a fail-safe feature. That is: In the event of failure of the accessory turn signals due to an electronic defect, an error message is immediately displayed in the cockpit. Features The following resistance values can be set: 150 Ohm 170 Ohm 200 Ohm 240 Ohm 300 Ohm 400 Ohm 600 Ohm 1200 Ohm

Dimensions Height = 11 mm Width = 31 mm (without lugs) Width = 46 mm (with lugs) length = 40 mm Cable length = 200 mm with pins Connections Yellow = Input channel 1 (+) Orange = Output channel 1 (+) Blue = input channel 2 (+) Red = Output channel 2 (+) Gray = Input ground (-) Black = Output ground (-) Scope of delivery 1 piece CAN-BUS resistor CBW1 2...

...
