SHIN YO Mini taillight TEXAS. 12 volt 21/5 watt tail light & brake light function in housing with adjustable bracket & license plate light.

Dimensions Glass diameter 50 mm Housing diameter approx. 85 mm Scope of delivery 1 piece mini taillight Note ONLY the tail light is E-approved, the license plate light is WITHOUT test mark.

...

SHIN YO Mini taillight TEXAS. 12 volt 21/5 watt tail light & brake light function in housing with adjustable bracket & license plate light.

Dimensions Glass diameter 50 mm Housing diameter approx. 85 mm Scope of delivery 1 piece mini taillight Note ONLY the tail light is E-approved, the license plate light is WITHOUT test mark.

...

SHIN YO MOVE type 2 universal LED taillight / brake light combination with license plate holder & license plate light in a black metal housing & tinted glass. The tail light is removable, E-approved.

Dimensions taillight

Width: 47 mm

Height: 15 mm

Depth: 43 mm

Dimensions license plate holder

Width: 179 mm

Height: 27 mm Thickness: 2 mm Connections Black = ground (-) Yellow = taillight (+) Red = brake light (+) Scope of delivery 1 piece tail light / brake light combination 255-162













...

SHIN YO LED turn signal TOLEDO. The latest lighting technology in a robust plastic housing in black with tinted glass, E-approved.

Dimensions

Width: 50 mm Total

Width: approx. 62.5 mm

Height: 22 mm

Depth: 27 mm Threaded bolt: M8 Connections Yellow cable = turn signal (+) Black cable = ground (-) Scope of delivery 1 pair of LED turn signal 203-092









...

SHIN YO Halogen Turn Signal TOLEDO Triangular turn signal with robust plastic housing in black & yellow glass, E-approved.



...

SHIN YO LED main headlight Twin with low beam & high beam. The LED headlight set in a sturdy metal housing for side mount gives your bike that special look. The 4 inch low beam & high beam headlight is universally usable for all motorcycle conversions. Available in chrome & black finish, E-approved. It is necessary to connect a parking light separately, as this is not integrated in any of the headlights.

Dimensions

Height: 107 mm

Width: 215 mm

Depth: 130 mm Depth from thread: 60 mm Diameter inserts: 91 mm each Cable length: approx. 600 mm

Material: metal side mount: side mount Connections White = low beam (+) Blue = high beam (+) Green = Ground (-) With wiring harness & 3-pin connector for H4 Variants 223-432
- Black 223-433
- Chrome plated Scope of delivery 1 piece main headlight Note Without parking light, please order separately if necessary.











...

SHIN YO LED main headlight Twin with low beam & high beam. The LED headlight set in a sturdy metal housing for side mount gives your bike that special look. The 4 inch low beam & high beam headlight is universally usable for all motorcycle conversions. Available in chrome & black finish, E-approved. It is necessary to connect a parking light separately, as this is not integrated in any of the headlights.

Dimensions

Height: 107 mm

Width: 215 mm

Depth: 130 mm Depth from thread: 60 mm Diameter inserts: 91 mm each Cable length: approx. 600 mm

Material: metal side mount: side mount Connections White = low beam (+) Blue = high beam (+) Green = Ground (-) With wiring harness & 3-pin connector for H4 Variants 223-432
- Black 223-433
- Chrome plated Scope of delivery 1 piece main headlight Note Without parking light, please order separately if necessary.











...

SHIN YO 12V universal LED parking light, with plastic nut for mounting, E-approved.

Dimensions Lens head 23 mm Thread

...

SHIN YO universal handlebar mirror. Aerodynamically shaped mirror with a black housing, E-approved.

Dimensions Width

...

SHIN YO LED rear, brake light, turn signal V-SCOPE, for rear E-approved. Modern 3-in-1 turn signal with black plastic housing in arrowhead shape & slightly tinted glass. Innovative lighting technology with very bright SMD LEDs. In the center of the illuminated area is the turn signal & in the outer area in V-shape is the highly visible taillight & brake light. This shapely 3-in-1 turn signal has a total width of 6.6 cm with stem a pleasing size, not too big & not too small.

Dimensions

Height: 30.5 mm

Width: 54 mm

Depth: 27, 5 mm Rubber stem 12 mm Total width with rubber stem: 66 mm Threaded bolt: M8x 1.25 Connections Yellow cable = tail light (+) Red cable = brake light (+) Blue cable = turn signal (+) Black cable = ground (-) Scope of delivery 1 pair tail light, brake light, turn signal 254-082







...
