SHIN YO LED turn signal TOLEDO. The latest lighting technology in a robust plastic housing in black with tinted glass, E-approved.

Dimensions

Width: 50 mm Total

Width: approx. 62.5 mm

Height: 22 mm

Depth: 27 mm Threaded bolt: M8 Connections Yellow cable = turn signal (+) Black cable = ground (-) Scope of delivery 1 pair of LED turn signal 203-092









...

SHIN YO Halogen Turn Signal TOLEDO Triangular turn signal with robust plastic housing in black & yellow glass, E-approved.



...

SHIN YO 12 V universal TRI-LED parking light. A small parking light with three bright LEDs. With holder, screws & self-adhesive 3M foil for mounting, E-approved.

Dimensions Length: 40 mm

Height: 10 mm

Depth: 17 mm Scope of delivery 1 piece parking light 223-323 Mounting hardware





...

SHIN YO LED main headlight Twin with low beam & high beam. The LED headlight set in a sturdy metal housing for side mount gives your bike that special look. The 4 inch low beam & high beam headlight is universally usable for all motorcycle conversions. Available in chrome & black finish, E-approved. It is necessary to connect a parking light separately, as this is not integrated in any of the headlights.

Dimensions

Height: 107 mm

Width: 215 mm

Depth: 130 mm Depth from thread: 60 mm Diameter inserts: 91 mm each Cable length: approx. 600 mm

Material: metal side mount: side mount Connections White = low beam (+) Blue = high beam (+) Green = Ground (-) With wiring harness & 3-pin connector for H4 Variants 223-432
- Black 223-433
- Chrome plated Scope of delivery 1 piece main headlight Note Without parking light, please order separately if necessary.











...

SHIN YO LED main headlight Twin with low beam & high beam. The LED headlight set in a sturdy metal housing for side mount gives your bike that special look. The 4 inch low beam & high beam headlight is universally usable for all motorcycle conversions. Available in chrome & black finish, E-approved. It is necessary to connect a parking light separately, as this is not integrated in any of the headlights.

Dimensions

Height: 107 mm

Width: 215 mm

Depth: 130 mm Depth from thread: 60 mm Diameter inserts: 91 mm each Cable length: approx. 600 mm

Material: metal side mount: side mount Connections White = low beam (+) Blue = high beam (+) Green = Ground (-) With wiring harness & 3-pin connector for H4 Variants 223-432
- Black 223-433
- Chrome plated Scope of delivery 1 piece main headlight Note Without parking light, please order separately if necessary.











...

SHIN YO universal handlebar mirror. Aerodynamically shaped mirror with a black housing, E-approved.

Dimensions Width

...

SHIN YO LED rear, brake light, turn signal V-SCOPE, for rear E-approved. Modern 3-in-1 turn signal with black plastic housing in arrowhead shape & slightly tinted glass. Innovative lighting technology with very bright SMD LEDs. In the center of the illuminated area is the turn signal & in the outer area in V-shape is the highly visible taillight & brake light. This shapely 3-in-1 turn signal has a total width of 6.6 cm with stem a pleasing size, not too big & not too small.

Dimensions

Height: 30.5 mm

Width: 54 mm

Depth: 27, 5 mm Rubber stem 12 mm Total width with rubber stem: 66 mm Threaded bolt: M8x 1.25 Connections Yellow cable = tail light (+) Red cable = brake light (+) Blue cable = turn signal (+) Black cable = ground (-) Scope of delivery 1 pair tail light, brake light, turn signal 254-082







...

SHIN YO LED sequence blinker WIPE, black, tinted glass, E-approved. The modern turn signal with built-in running light system, lightweight plastic housing & tinted glass has the latest lighting technology. When flashing, the individual LEDs light up one after the other from the inside to the outside, creating a wiping effect like current passenger car models. The trendy running light is a real eye-catcher with which your vehicle stands out in traffic & thus increases road safety. Even with the tinted glass, the turn signal is well perceived by the running light in road traffic. The turn signal is suitable for front & rear.

Dimensions

Width: 61 mm Total

Width: 77 mm

Height: 17.5 mm

Depth: 14 mm Rubber stem: 15 mm Threaded bolt: M8 Weight: 0, 021kg Connections Power input: Yellow cable = turn signal (+) 12 V Black cable = Ground (-) Scope of delivery 1 Pair sequence flasher 203-029









...

SHIN YO LED taillight / brake light X-WING. The flexible tail light with black plastic housing is made for uncomplicated conversion. The shapely wings are adjustable by 20 degrees & thus adapt well. Adjustable 10 degrees down & 10 degrees up. Suitable for screwing on or laminating, E-approved.

Dimensions

Width: 137.2 mm Height at pivot point: 16 mm Height at the wing: 13 mm

Depth: 20.8 mm Connections Green = Ground (-) Blue = brake light (+) Yellow = driving light (+) Variants 255-680
- Black Clear 255-682
- Chrome red Scope of delivery 1 piece tail light / brake light







...

SHIN YO LED taillight / brake light X-WING. The flexible tail light with black plastic housing is made for uncomplicated conversion. The shapely wings are adjustable by 20 degrees & thus adapt well. Adjustable 10 degrees down & 10 degrees up. Suitable for screwing on or laminating, E-approved.

Dimensions

Width: 137.2 mm Height at pivot point: 16 mm Height at the wing: 13 mm

Depth: 20.8 mm Connections Green = Ground (-) Blue = brake light (+) Yellow = driving light (+) Variants 255-680
- Black Clear 255-682
- Chrome red Scope of delivery 1 piece tail light / brake light







...
