HIGHSIDER LED taillight / brake light combination GOTHIC. Tail light with power LED in a plastic housing in cross design & clear glass lens, E-approved. Be seen with safety -the tail light & taillight/turn signal series from HIGHSIDER give you the safety you need & the look you want
- whether cruiser, scooter or speedster.

Dimensions

Width: 74 mm

Height: 64 mm

Depth: 20.5 mm Mounting: with 2 x M4- screws on the back, hole spacing: 40 mm. Connections Black cable = ground (-) Yellow cable = rear light (+) Red cable = brake light (+) Variants 255-095
- Black 255-096
- Chrome plated Scope of delivery 1 piece tail light










...

HIGHSIDER LED taillight / brake light combination GOTHIC. Tail light with power LED in a plastic housing in cross design & clear glass lens, E-approved. Be seen with safety -the tail light & taillight/turn signal series from HIGHSIDER give you the safety you need & the look you want
- whether cruiser, scooter or speedster.

Dimensions

Width: 74 mm

Height: 64 mm

Depth: 20.5 mm Mounting: with 2 x M4- screws on the back, hole spacing: 40 mm. Connections Black cable = ground (-) Yellow cable = rear light (+) Red cable = brake light (+) Variants 255-095
- Black 255-096
- Chrome plated Scope of delivery 1 piece tail light










...

HIGHSIDER hand protectors with LED daytime running light & parking light. The ingenious accessory for all enduro riders
- hand
...

This adapter expands your options when choosing a mirror from the HIGHSIDER accessories program for your Harley-Davidson. Herewith you can attach, right & left, all mirrors with an M8 internal thread in the stem to your Harley. Variants 304-011
- Chrome plated 304-012
- Black Scope of delivery 1 piece mirror adapter

...

This adapter expands your options when choosing a mirror from the HIGHSIDER accessories program for your Harley-Davidson. Herewith you can attach, right & left, all mirrors with an M8 internal thread in the stem to your Harley. Variants 304-011
- Chrome plated 304-012
- Black Scope of delivery 1 piece mirror adapter

...

HIGHSIDER Headlight IOWA H4 halogen main headlight including parking light with clear or blue glass in a chrome or black oval metal housing for bottom mount. The reflector emits a bright, symmetrical light
- for good road illumination & optimum visibility, E-approved See & be seen
- give your bike a distinctive style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case! Technical specifications Illuminant: H4, 12 V 60/55W

Width: 175 mm

Height: 102 mm

Depth: 132 mm Side mount lamp ring: side mount with M3 socket head screws, M3 x 0.5 mm, length: 15 mm, (actual thread length: 12 mm), head diameter: 5 mm. Bottom mount: M10 Connections Black cable = ground (-) Yellow cable = low beam (+) Blue cable = high beam (+) Parking light Green cable = parking light (+) Black cable = ground (-) Variants 223-060
- Chrome/blue-tinted 223-062
- Black/blue-tinted 223-063
- Chrome/ Clear 223-064
- Black/ Clear Scope of delivery 1 piece H4 headlight











...

HIGHSIDER Headlight IOWA H4 halogen main headlight including parking light with clear or blue glass in a chrome or black oval metal housing for bottom mount. The reflector emits a bright, symmetrical light
- for good road illumination & optimum visibility, E-approved See & be seen
- give your bike a distinctive style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case! Technical specifications Illuminant: H4, 12 V 60/55W

Width: 175 mm

Height: 102 mm

Depth: 132 mm Side mount lamp ring: side mount with M3 socket head screws, M3 x 0.5 mm, length: 15 mm, (actual thread length: 12 mm), head diameter: 5 mm. Bottom mount: M10 Connections Black cable = ground (-) Yellow cable = low beam (+) Blue cable = high beam (+) Parking light Green cable = parking light (+) Black cable = ground (-) Variants 223-060
- Chrome/blue-tinted 223-062
- Black/blue-tinted 223-063
- Chrome/ Clear 223-064
- Black/ Clear Scope of delivery 1 piece H4 headlight











...

HIGHSIDER Headlight IOWA H4 halogen main headlight including parking light with clear or blue glass in a chrome or black oval metal housing for bottom mount. The reflector emits a bright, symmetrical light
- for good road illumination & optimum visibility, E-approved See & be seen
- give your bike a distinctive style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case! Technical specifications Illuminant: H4, 12 V 60/55W

Width: 175 mm

Height: 102 mm

Depth: 132 mm Side mount lamp ring: side mount with M3 socket head screws, M3 x 0.5 mm, length: 15 mm, (actual thread length: 12 mm), head diameter: 5 mm. Bottom mount: M10 Connections Black cable = ground (-) Yellow cable = low beam (+) Blue cable = high beam (+) Parking light Green cable = parking light (+) Black cable = ground (-) Variants 223-060
- Chrome/blue-tinted 223-062
- Black/blue-tinted 223-063
- Chrome/ Clear 223-064
- Black/ Clear Scope of delivery 1 piece H4 headlight











...

HIGHSIDER Headlight IOWA H4 halogen main headlight including parking light with clear or blue glass in a chrome or black oval metal housing for bottom mount. The reflector emits a bright, symmetrical light
- for good road illumination & optimum visibility, E-approved See & be seen
- give your bike a distinctive style! The unusual design & perfect technology of the HIGHSIDER headlight series make it a highlight in any case! Technical specifications Illuminant: H4, 12 V 60/55W

Width: 175 mm

Height: 102 mm

Depth: 132 mm Side mount lamp ring: side mount with M3 socket head screws, M3 x 0.5 mm, length: 15 mm, (actual thread length: 12 mm), head diameter: 5 mm. Bottom mount: M10 Connections Black cable = ground (-) Yellow cable = low beam (+) Blue cable = high beam (+) Parking light Green cable = parking light (+) Black cable = ground (-) Variants 223-060
- Chrome/blue-tinted 223-062
- Black/blue-tinted 223-063
- Chrome/ Clear 223-064
- Black/ Clear Scope of delivery 1 piece H4 headlight











...

HIGHSIDER handlebar end mirror in cross design with an aluminum head. Suitable for handlebars with a handlebar inner diameter of 12 to 21 mm, ie for most 7/8-inch & 1-inch aluminum or steel handlebars. Can be used for left & right side, E-approved. A question of view
- retro or modern. The HIGHSIDER mirror series are characterized by characteristic design & aerodynamic function. So you keep the overview.

Dimensions

Width: 110 mm

Height: 110 mm

Depth: 20 mm Length, arm to joint: 70 mm Length, arm to clamp: 115 mm Width, clamp: 12 mm Variants 301-112
- Black 301-113
- Chrome plated Scope of delivery 1 pc. incl. reducing rings for 1 inch & 7/8 inch Note To close any holes for mounting the original handlebar mirrors, use the HIGHSIDER closing caps: No. 160-314










...
