SHIN YO LED daytime running light with parking light function. The LED daytime running light with several dozen power LEDs & parking light function ensures that bikers are well perceived by other road users. Packaged in a matte black rectangular plastic housing, the daytime running light is manufactured for universal mounting. With this daytime running light, the light switches to dimmed parking light mode (position light) when switching to low beam, E-approved. See & be seen
- give your bike personality!

Dimensions

Width: 150 mm

Height: 17 mm

Depth: 37.5 mm

Dimensions U-Holder Width holder: 100 mm Height holder: 15.5 mm Holder

Depth: 27.5 mm Thickness: 1, 5 mm Connections Black = ground (-) Red = connect to switched positive (ignition 15+)t White = connect control line to parking light (+) Scope of delivery 1 piece daytime running light 222-503 Notes Prerequisite is a manually switched low beam (light switch), otherwise the function of the TFL would be disabled. According to the regulations, the TFL must be connected so that it goes out when the main headlight is switched on. (Exception: headlight flasher). The rear tail light must always remain switched on, i.e. set to ignition plus. If there are other parking lights on the vehicle, these must be disconnected, as there may be a maximum of 2 parking lights on the vehicle. Optionally available HIGHSIDER DRL CONTROL- BOX CB1, daytime running light control box for vehicles without light switch, 12V No. 208-108 Light switch on/off with clamp for handlebar mounting e.g. No. 240-044












...

SHIN YO 12V MINI LED parking light, with plastic nut for fixing, E-approved.

Dimensions Lens head: 14.8 mm Thread

...

SHIN YO LED parking light. 100% waterproof with plastic housing & universal metal holder, E-approved.

Dimensions

...

SHIN YO LED parking light, with a metal housing & a M12 screw for mounting, E-approved.

Dimensions Diameter 24.7

...

SHIN YO LED taillight / brake light with plastic frame & splash guard. LED tail light with license plate illumination & red glass, including universal plastic frame in black for mounting on the rear of the vehicle. The plastic frame has three holes for mounting, is with a license plate holder & also serves as a splash guard, E-approved.

Dimensions plastic frame

Width: 96 mm Length top to tail light: 200 mm Splash guard / license plate holder: width 95 mm x length 150 mm Distance of the three holes for mounting: 65 mm & 145 mm to the top hole at the beginning

Dimensions rear light

Width: 84 mm

Height: 22 mm

Depth: 39 mm Scope of delivery 1 piece tail light / brake light with plastic frame 255-677 Note The license plate light is only tested for license plates with a max. size of 240 mm x 130 mm











...

SHIN YO round 12 volt 21/5 watt tail light with brake light function in black housing with license plate light. ONLY the tail light is E-approved, the license plate light is WITHOUT test mark.

Dimensions Housing diameter: 55 mm Glass diameter: 45 mm

Depth: 75 mm Scope of delivery 1 piece tail light 255-990 Note License plate light is WITHOUT test mark.



...

SHIN YO LED license plate light with 4 LEDs, ABS black, E-approved

Dimensions W x H x D = 56 x 20 x 26 mm Scope

...

SHIN YO LED license plate light made from ABS plastic, black, E-approved.

Dimensions

Height:



...

SHIN YO LED license plate light, black housing, E-approved.

Dimensions Height 13 mm Width 47 mm Depth 20 mm Mounting

...

SHIN YO MINI LED license plate light in black with 3 LEDs & holder, E-approved.

Dimensions

Width:



...
