HIGHSIDER CNC fairing mirror adapter FB-1 short or long selectable, set. The CNC fairing mirror adapters are attached to the fairing, where originally the OEM fairing mirrors were installed. A special screw adapter (M6, M8) is screwed into the handlebar mirror e.g. HIGHSIDER VICTORY 301-027 (not included) & in turn attached to the CNC fairing mirror adapter.

Dimensions version short (304-029) Length: 61 mm

Width: 18 mm Screw hole spacing: 8-43 mm

Dimensions version long (304-030) Length: 77.5 mm

Width: 18 mm Screw hole spacing: 8-59 mm Scope of delivery 2 x CNC fairing mirror adapter short or long 2 x screw adapter M6 2 x screw adapter M8 4 x screws M6 x 30 mm 2 x screws M6 x 15 mm 4 x M6 self-locking nut 4 x washer D.9, 8 x 6 x 1, 3 mm 4 x washer D.11, 8 x 6 x 1, 4 mm 4 x bushing D.10.4 x 6 x 7 mm 4 x socket D.11 x 6 x 10 mm 4 x mirror adapter for fastening to the holder Notes For mirrors 301-027, 301-050, 301-447, 301-573, 301-580 & 301-582 CNC fairing mirror adapter long, No. 304-03...







...

HIGHSIDER FERRARA 2 EVO handlebar end mirror, usable for left & right side, E-approved. Black anodized handlebar end mirror in a sporty design with a head made from aluminum & a bent stem
- without kink as in the HIGHSIDER FERRARA 2 model. Suitable for handlebars with an inner handlebar diameter of 12 to 22 mm, i.e. for most 7/8-inch & 1-inch aluminum or steel handlebars. Character & overview
- whether retro or modern. The HIGHSIDER mirror series are characterized by characteristic design & aerodynamic function. This is circumspection in perfection.

Dimensions Width, head: 122 mm Height, head: 85 mm

Depth: 24 mm Length, handle: approx. 130 mm Central screw: M6 x 1.0 mm hexagon socket screw Scope of delivery 1 piece handlebar end mirror 301-784, including mounting kit & universal clamping system. Notes For conversion, loosen the five M4 screws & reattach the intermediate adapter on the other side. To close any holes for mounting the original handlebar mirrors, please use the...





...

HIGHSIDER FERRARA 2-XL mirror, E-approved, surface finely bead-blasted in black satin. The XL generation of the popular HIGHSIDER FERRARA 2 has a 25 mm longer aluminum arm for the best possible view to the rear. So you get, for example, the elbow or knee of the pillion out of the field of view. The aluminum spear head has a corrosion-resistant stainless steel ball clamp & allows precise adjustment of the mirror. The assembly takes place classically in the handlebar fitting. The screw connection with the handlebar fittings is made via an adapter (M10x 1.25) & is therefore suitable for most models on the market. For Yamaha models with left-hand thread is a corresponding adapter included. Can be used for left & right side. Prudence with style
- whether classic or modern. The HIGHSIDER mirror series are characterized by striking design & aerodynamic function. So you can keep an overview.

Dimensions A Width head: 122 mm B Height head: 85 mm C Total

Width: 197 mm D Total

Height: 176 m...






...

Noble handlebar end mirror in a sporty design with a head made from aluminum. Suitable for handlebars with an inner handlebar diameter of 12 to 21 mm, i.e. for most 7/8-inch & 1-inch aluminum or steel handlebars. Can be used for left & right side, E-approved. Prudence with style
- whether classic or modern. The HIGHSIDER mirror series are characterized by striking design & aerodynamic function. So you can keep an overview.

Dimensions A: Width head 120 mm B: Height head 85 mm C: Width 90 mm D: Height 180 mm

Depth: 24 mm Length, arm to bend: 70 mm Length, arm to end of clamp: 115 mm Width, clamp: 12 mm Variants 301-782
- Black 301-783
- Chrome plated Scope of delivery 1 piece handlebar end mirror, incl. reducing rings for 1 inch & 7/8 inch Note To close any holes for mounting the original handlebar mirrors, use the HIGHSIDER closing caps.






...

Noble handlebar end mirror in a sporty design with a head made from aluminum. Suitable for handlebars with an inner handlebar diameter of 12 to 21 mm, i.e. for most 7/8-inch & 1-inch aluminum or steel handlebars. Can be used for left & right side, E-approved. Prudence with style
- whether classic or modern. The HIGHSIDER mirror series are characterized by striking design & aerodynamic function. So you can keep an overview.

Dimensions A: Width head 120 mm B: Height head 85 mm C: Width 90 mm D: Height 180 mm

Depth: 24 mm Length, arm to bend: 70 mm Length, arm to end of clamp: 115 mm Width, clamp: 12 mm Variants 301-782
- Black 301-783
- Chrome plated Scope of delivery 1 piece handlebar end mirror, incl. reducing rings for 1 inch & 7/8 inch Note To close any holes for mounting the original handlebar mirrors, use the HIGHSIDER closing caps.






...

Handlebar mirror with an aluminum head & adjustable stem. Thanks to the use of a second joint on the stem, there are additional adjustment options for your safety.

Includes:: extra adapter M10 x 1.25 mm with left-hand thread for Yamaha. Can be used for left & right side. Prudence with style
- whether classic or modern. The HIGHSIDER mirror series are characterized by striking design & aerodynamic function. So you can keep an overview.

Dimensions A Width head: 120 mm B Height head: 85 mm C Total

Width: 200 mm D Total

Height: 150 mm Depth head: 24 mm Length, arm to joint: 150 mm Length, arm to threaded bolt: 180 mm Blind hole M8 x 1.25 mm Variants 301-780
- Black 301-781
- Chrome plated Scope of delivery 1 piece rear view mirror Adapter M10 x 1, 25 mm with left hand thread for Yamaha










...

HIGHSIDER 4 3/4 inch LED headlight FLAT TYPE 9 with parking light ring, E-approved. With its compact 4 3/4 inch dimension, the LED headlight FLAT TYPE 9 makes a good figure on your bike. Small but still robust. Powerful LED technology solidly packaged in a steel housing with round shape & flat back. Tested main headlight with high beam, low beam & parking light function. The low beam is at the bottom & the high beam is at the top. The LED parking light is ring-shaped & surrounds the reflector, forming a light ring.

Dimensions Diameter housing: 138 mm Diameter insert: 120 mm Depth housing: 95 mm Bottom mount: M10 screw, L:25 mm Weight: 0, 992kg Connections Power input: 3 pin connector Red = high beam (+) White = low beam (+) Green = position light (+) Black = Ground (-) Scope of delivery 1 piece main headlight 223-194

...

A highlight of the HIGHSIDER product development: the slim & sporty design, the high-quality aluminum housing & the tinted glass seamlessly inserted into it, make this turn signal a real premium product. Install the handlebar end turn signal HIGHSIDER FLIGHT, separately or optionally, with our handlebar end mirrors, such as the new HIGHSIDER CONERO 2 (- see picture) or our TOPSELLER HIGHSIDER VICTORY. Moving the handlebar fittings is no longer necessary due to the unique mounting system we have developed. With this system, the mounting is done easily & quickly! Modern LEDs in SMD design provide excellent luminosity & make the HIGHSIDER FLIGHT handlebar end turn signal a real eye-catcher! Features Suitable for handlebar tube inner diameter from 12 to 22 mm E-approved for use as a front turn signal Incl. mounting kit & universal clamping system Prudence with style
- whether classic or modern. The HIGHSIDER mirror series are characterized by striking design & aerodynamic funct...
...

HIGHSIDER LED turn signal FLIGHT. The turn signal with the high-quality aluminum housing convinces with its unusual design. The tinted glass inserted flush into the CNC-milled housing, gives an angular & compact impression when viewed from the front. On the back, on the other h&, soft curves dominate, underlining the sporty character of the FLIGHT. The flexible rubber stem blends seamlessly into the black housing. Modern LEDs in SMD design provide excellent luminosity & make the FLIGHT turn signal a real eye-catcher! E-approved for use as front & rear turn signal. Prudence with style
- whether classic or modern. The HIGHSIDER mirror series are characterized by striking design & aerodynamic function. This is how you keep the overview.

Dimensions A: 30 mm B: 41 mm (rubber stem 11 mm) C: 16.5 mm D: 22 mm Threaded bolt: M8 x 19 mm Connections Yellow cable = turn signal (+) Black cable = ground (-) Scope of delivery 1 pair of LED turn signals 203-002


...

Aluminum turn signal holder, black, for CNC aluminum fork pipe clamps. Scope of delivery 1 pair of turn signal holder 207-122 ...
