SHIN YO LED rear, brake light, turn signal ARROWHEAD, E-approved for rear. A modern designed turn signal with integrated tail light. The latest lighting technology in a robust plastic housing in black, with rubber stem & red glass. A transparent area for the turn signal light is incorporated into the glass.

Dimensions 57 x 69 x 22 mm Threaded bolt: M8 x 1.25 mm Connections Yellow cable = tail light (+) Red cable = brake light (+) Blue cable = turn signal (+) Black cable = ground (-) Scope of delivery 1 pair tail light, brake light, turn signal 254-078

...

SHIN YO ARROWHEAD LED turn signal/position light, E-approved for front. A modern designed turn signal with integrated position light. The latest lighting technology in a sturdy plastic housing in black, with rubber stem & tinted glass.

Dimensions 57 x 69 x 22 mm Threaded bolt: M8 x 1.25 mm Connections Yellow cable = turn signal (+) White cable = position light (+) Black cable = ground (-) Scope of delivery 1 pair of turn signal/position light 204-078

...

Main headlight with parking light, metal housing, HS1 12V 35/35 W, bottom mount, E-approved. Ideal for ATV conversions.



...

Main headlight with parking light, metal housing, HS1 12V 35/35 W, bottom mount, E-approved. Ideal for ATV conversions.



...

SHIN YO LED tail light, brake light, turn signal for ATV & others. Black housing, clear turn signal glass u. red tail light glass, pair with passenger car approval according to ECE R6 & R7, E-approved.

Dimensions Depth 3.5cm Diameter 80 mm 2 x M6 mounting bolts (length 22 mm) on the back at a distance of 50 mm Scope of delivery 1 pair of tail light, brake light, turn signal 254-030

...

SHIN YO 4 1/2 inch clear lens spotlight Bates style. The popular main headlight with its classic style in hemisphere shape makes the pig headlight the perfect part for all conversion projects. The E-approved headlight is also durable & easy to install. Technical data Metal housing Prismatic reflector Clear glass H3 insert 12V/55W Fixing point: bottom

Dimensions Diameter headlamp insert: 115 mm

Depth: 100 mm Depth from mounting to end of housing: 55 mm Scope of delivery 1 piece clear glass spotlight 222-040



...

SHIN YO 5 3/4 inch headlight Bates Style. E-approved. The popular main headlight with its classic style in hemisphere shape makes the headlight the perfect part for all conversion projects. The tested headlight is also robust & easy to install. Technical data Metal housing Embossed glass H4 insert with parking light H4 12V 60/55W fixing point: bottom

Dimensions housing diameter: 155 mm diameter headlight insert: 146 mm depth without glass: 110 mm Variants 222-019
- Black 222-026
- Chrome plated Scope of delivery 1 piece main headlight



...

SHIN YO 5 3/4 inch headlight Bates Style. E-approved. The popular main headlight with its classic style in hemisphere shape makes the headlight the perfect part for all conversion projects. The tested headlight is also robust & easy to install. Technical data Metal housing Embossed glass H4 insert with parking light H4 12V 60/55W fixing point: bottom

Dimensions housing diameter: 155 mm diameter headlight insert: 146 mm depth without glass: 110 mm Variants 222-019
- Black 222-026
- Chrome plated Scope of delivery 1 piece main headlight



...

Bates style 5 3/4 inch main headlight, E-approved. The popular main headlight with its classic look in hemisphere shape makes the pig headlight the perfect part for all conversion projects. The headlight is also robust & easy to install. Features Metal housing Clear glass Prismatic reflector, asymmetrical H4 insert with parking light H4 12V 60/55W Side mount or bottom mount

Dimensions Diameter insert: 146 mm Housing diameter: 155 mm Depth without glass: 110 mm Distance between mounting points on the side: approx. 155 mm Variants 222-021
- Chrome plated, side mount 222-023
- Black, side mount 222-024
- Matte black, side mount 222-017
- Black, bottom mount 222-018
- Black/copper, bottom mount 222-020
- Chrome, bottom mount Scope of delivery 1 piece main headlight







...

Bates style 5 3/4 inch main headlight, E-approved. The popular main headlight with its classic look in hemisphere shape makes the pig headlight the perfect part for all conversion projects. The headlight is also robust & easy to install. Features Metal housing Clear glass Prismatic reflector, asymmetrical H4 insert with parking light H4 12V 60/55W Side mount or bottom mount

Dimensions Diameter insert: 146 mm Housing diameter: 155 mm Depth without glass: 110 mm Distance between mounting points on the side: approx. 155 mm Variants 222-021
- Chrome plated, side mount 222-023
- Black, side mount 222-024
- Matte black, side mount 222-017
- Black, bottom mount 222-018
- Black/copper, bottom mount 222-020
- Chrome, bottom mount Scope of delivery 1 piece main headlight







...
