HIGHSIDER PROTON THREE 3in 1 LED tail light, brake light, turn signal, for rear E-approved
- small, smaller, HIGHSIDER PROTON.
...

HIGHSIDER PROTON THREE LED position light, for front E-approved
- small, smaller, HIGHSIDER PROTON. With a HIGHSIDER PROTON
...

HIGHSIDER PROTON THREE LED taillight, E-approved
- small, smaller, HIGHSIDER PROTON. With a HIGHSIDER PROTON taillight, the
...

HIGHSIDER PROTON THREE LED turn signal, E-approved for front & rear
- small, smaller, HIGHSIDER PROTON. With a HIGHSIDER PROTON
...

HIGHSIDER PROTON TWO 3in 1 LED tail light, brake light, turn signal, E-approved for rear.
- small, smaller, HIGHSIDER PROTON.
...

HIGHSIDER PROTON TWO LED turn signal, E-approved for front & rear
- small, smaller, HIGHSIDER PROTON. With a HIGHSIDER PROTON
...

HIGHSIDER PROTON TWO 2in 1 LED turn signal / position light, E-approved for front
- small, smaller, HIGHSIDER PROTON. With a
...

Extremely small, load-independent digital flasher unit that is ideal for LED flasher conversions or for conventional 10 watt or 21 watt flasher bulbs. The relay provides an absolutely constant flashing frequency & fits in almost all steering tubes or frames. Precisely tuned
- the extensive range of accessories from HIGHSIDER is perfectly tailored to your motorcycle. With the highest level of quality & functionality, you can easily customize your bike to your liking.

Dimensions Length: 15 mm

Width: 8 mm

Height: 7 mm Technical specifications Supply voltage: 8 V
- 18 V Load range: 0.1 W
- 42 W per side Simple connections via 2 wires Connect red cable = 12 V (+) with terminal 49, it is recommended to connect a 10 A fuse in front of it Black cable = connect ground (-) in series to turn signal switch with terminal 49a Scope of delivery 1 piece flasher unit 208-014 Notes With various English Fahrzeigen (BSA, Norton, etc.) all consumers are connected to ground, plus is connected to the fra...








...

HIGHSIDER 7 inch LED headlight RENO TYPE 3 for side mount. Innovative power LED headlight with parking light function & clear glass. The oval metal housing, has a chrome-plated, asymmetrical
- only approved for right-hand traffic
- reflector, E-approved. HIGHSIDER highlights
- give your bike a distinctive style! The unusual design & the perfect technology of the HIGHSIDER headlight series make it a highlight in any case!

Dimensions Housing diameter: 200 mm Headlight insert diameter: 178 mm Housing

Depth: 160 mm Distance of mounting holes (center
- center): 170 mm Distance of mounting hole (center) to end of housing: approx. 90 mm Side mount with M8 threaded bolt Connections 3-pin plug type A, female Cable length 210 mm (included) Green cable = ground (-) Blue cable = high beam (+) White cable = low beam (+) At reflector in headlight housing Black cable = ground (-) Red cable = low beam (+), current consumption: at 12 volts 18 watts, approx. 1132 lumens. White cable = high beam (+), . ..







...

HIGHSIDER 7 inch LED headlight RENO TYPE 3 for side mount. Innovative power LED headlight with parking light function & clear glass. The oval metal housing, has a chrome-plated, asymmetrical
- only approved for right-hand traffic
- reflector, E-approved. HIGHSIDER highlights
- give your bike a distinctive style! The unusual design & the perfect technology of the HIGHSIDER headlight series make it a highlight in any case!

Dimensions Housing diameter: 200 mm Headlight insert diameter: 178 mm Housing

Depth: 160 mm Distance of mounting holes (center
- center): 170 mm Distance of mounting hole (center) to end of housing: approx. 90 mm Side mount with M8 threaded bolt Connections 3-pin plug type A, female Cable length 210 mm (included) Green cable = ground (-) Blue cable = high beam (+) White cable = low beam (+) At reflector in headlight housing Black cable = ground (-) Red cable = low beam (+), current consumption: at 12 volts 18 watts, approx. 1132 lumens. White cable = high beam (+), . ..







...
